Cummins RS25 Quiet Connect 25kW Single Phase Standby Generator

Home
Standby Generators
Cummins RS25 Quiet Connect 25kW Single Phase Standby Generator

Cummins RS25 Quiet Connect 25kW Single Phase Standby Generator

Price:

US $8,450.00

SKU:

A051Y239

Brand:

Cummins Power

Condition:

New

Availability:

In Stock

Product Description

Cummins 25,000 Watt (25kW) Liquid-Cooled Quiet Connect Standby Generator 120/240V Single-Phase

The Cummins RS25 Generator operates in extreme environmental conditions. Handles cold weather starts down to -40° Fahrenheit. EPA Certified to the latest specifications and capable of NFPA 100 requirements when equipped with the necessary accessories. The RS25 has a flexible exercise mode to meet customer requirements-intervals low as 2 minutes every 6 months

The 2.4 Liter inline 4-cylinder engine runs at 1800 RPM on Natural Gas or Propane. Fuel type field selectable at installation. The generator produces just 69 dBA noise.

25kW Generator

The 25kW Generator produces 120/240 Volts at up to 104 Amps on both fuels. The advanced aluminum sound-level 1 enclosure design is aesthetically appealing and delivers excellent noise reduction. It withstands 180 MPH wind loads in accordance with ASCE 7-10. Removable doors provide easy access for service and maintenance.

PowerCommand electronic control with 128 x 64 backlit LED display is standard equipment for complete generator set system integration that includes remote start/stop, precise frequency and voltage regulation, alarm and status display, auto fault shutdown, and NFPA 110 Level 1 compliance. PowerCommand also delivers industry leading self-diagnostic capability. The design of critical generator components ensures the completion of service and preventative maintenance in a short period of time.

QuietConnect 25kW

The QuietConnect 25kW generators comes with factory-installed features:

Coolant Heater
Crank Case Vent Heater
Large Battery Rack
Flexible Fuel Line
Full Set of Literature including operator manual, installation quick guide and manual, and service manual.

The Cummins QuietConnect 25kW Generator has a Cummins 2-Year Limited Warranty. Extended warranties up to 10-Years are available.

RS25 Generators meet UL-2200, EPA Emissions for Emergency Stationary 40CFR60, IBC Seismic, and NFPA 110 (with optional accessories sold separately).

Factory Installed Coolant Heater, Battery Rack and Flexible Fuel Line Included.

Specifications

Design	Naturally aspirated
Bore	86.5 mm (3.4 in)
Stroke	100.0 mm (3.94 in)
Displacement	2.4 liters (143.5 in3)
Cylinder block	Cast iron, in-line 4 cylinder
Battery capacity	550 amps at ambient temperature of 0 oF to 32 oF (-18 oC to 0 oC)
Battery charging alternator	50 amps
Starting voltage	12 volt, negative ground
Lube oil filter type(s)	Spin-on with relief valve
Standard cooling system	50° C (122° F) ambient cooling system
Rated speed	1800 rpm
Governor regulation class	ISO 8528 Part 1 Class G3
Voltage regulation, no load to full load	±1.0%
Random voltage variation	±1.0%
Frequency regulation	Isochronous
Random frequency variation	± 0.25% @ 60 Hz
Radio frequency emissions compliance	FCC code Title 47 part 15 Class B
Minimum fuel supply pressure, kPa (in H2O)	1.5 (6.0)
Maximum fuel supply pressure, kPa (in H2O)	3.5 (14.0)
Weight	1109 lbs (503 kg)
Size	Length 72 in (1829 mm), width 34 in (864 mm), height 45.5 in (1156 mm)
Sound	64 dB(A) at 23 ft (7 m) with sound level 2 enclosure
